E V Controllers

EV Motor Controllers

Advanced Electronic Control Solutions for Electric Vehicles

SVCS develops sophisticated motor controllers for electric vehicles, providing precise control over BLDC, PMSM, and AC induction motors. Our controllers feature advanced vector control algorithms, regenerative braking, and comprehensive safety systems

Enquire Now
SVCS EV Motor Controllers

SVCS EV Motor Controllers

Advanced Electronic Control Solutions for Electric Vehicles

Key Features

Multi-Motor Support

Compatible with BLDC, PMSM, and AC induction motors

Advanced Control

Closed/open loop vector control technology

Regenerative Braking

Energy recovery system for extended range

Safety Systems

Multiple protection mechanisms and fail-safes

CAN Communication

Industry-standard CAN 2.0 bus communication

Programmable

Customizable parameters and control logic

Weather Resistant

IP67 protection rating

Technical Specifications

System Voltage:
48V, 60V, 72V, up to 750V DC options
Power Rating:
800W to 260kW continuous power
Current Rating:
30A to 350A peak current
Control Method:
Sensored/Sensorless vector control
Switching Frequency:
Up to 20kHz PWM frequency
Efficiency:
>97% at rated operating point
Operating Temperature:
-40°C to +85°C
Communication:
CAN 2.0B, RS485, analog I/O
Cooling:
Natural air cooling or liquid cooling options

Advanced Features

Electronic Key Switch

Anti-theft security system

Speed Control Modes

Eco, City, and Sports driving modes

Cruise Control

Constant speed maintenance

Slope Anti-Roll

Hill start assistance

E-ABS

Electronic braking assistance

Thermal Management

Smart temperature monitoring

Fault Diagnostics

Comprehensive error reporting

Protection Systems

Over-voltage and under-voltage protection
Over-current and over-temperature protection
Motor stall and phase loss detection
High pedal protection and safety interlocks
Reverse polarity and short-circuit protection
Charging protection during vehicle operation

Applications

🚗 Electric Cars and Light Commercial Vehicles
🏍️ Electric Motorcycles and Scooters
⛳ Golf Carts and Utility Vehicles
🛺 Electric Rickshaws and Three-wheelers
🏭 Industrial Electric Vehicles
🚤 Marine Electric Propulsion Systems

Control Interface

Throttle input (0-5V analog or PWM)
Brake signal input (digital/analog)
Direction control (forward/reverse)
Speed feedback and display output
Battery status monitoring
Motor temperature sensing
